 Post subject: Metallic Background
PostPosted: Mon Dec 09, 2013 1:32 pm  (#1)
Offline
Script Coder
User avatar

Joined: Apr 13, 2010
Posts: 244
Here's a script that will create this texture (default settings) and many more:


I've always loved this effect, but could never accomplish it until today. Here's the tutorial it's based on: http://www.tutorialwiz.com/metallic_background/

Here's the code for the script. Copy and paste the code into your favorite text editor and save it with a ".scm" extension. Save it here: C:\Program Files\GIMP-2.0\share\gimp\2.0\scripts and refresh your scripts. It can be found under Filters > Render > Ripple Texture...

; GIMP - The GNU Image Manipulation Program
; Copyright (C) 1995 Spencer Kimball and Peter Mattis
;
; This program is free software; you can redistribute it and/or modify
; it under the terms of the GNU General Public License as published by
; the Free Software Foundation; either version 2 of the License, or
; (at your option) any later version.
;
; This program is distributed in the hope that it will be useful,
; but WITHOUT ANY WARRANTY; without even the implied warranty of
; MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
; GNU General Public License for more details.
;
; You should have received a copy of the GNU General Public License
; along with this program; if not, write to the Free Software
; Foundation, Inc., 675 Mass Ave, Cambridge, MA 02139, USA.
;
;
;
;



; Define the Function

(define (fp-script-fu-ripple-texture
            drawable
            times
            hAmplitude
            vAmplitude
            period1
            period2
            wave1
            wave2
            hEdge
            vEdge
            hTrue
            vTrue
            )

(gimp-context-push)
(gimp-image-undo-group-start image)

(gimp-layer-add-alpha drawable)

(if (= wave1 0)
(set! wave1 1)
(set! wave1 0)
)

(if (= wave2 0)
(set! wave2 1)
(set! wave2 0)
)

(while (> times 0)

(plug-in-ripple RUN-NONINTERACTIVE image drawable period1 hAmplitude 0 hEdge wave1 TRUE hTrue)
(plug-in-ripple RUN-NONINTERACTIVE image drawable period2 vAmplitude 1 vEdge wave2 TRUE vTrue)
(gimp-displays-flush)
(set! times (- times 1))
)

(gimp-image-undo-group-end image)

(gimp-context-pop)

(gimp-displays-flush)


)

(script-fu-register "fp-script-fu-ripple-texture"
  "<Image>/Filters/Render/Ripple Texture..."
  "Create a random ripple texture somewhat similar to Photoshop's Wave Filter."
  "Art Wade"
  "Art Wade"
  "March 18, 2010"
  "RGB* GRAY*"
  SF-IMAGE          "Image" 0
  SF-DRAWABLE       "Drawable" 0
  SF-ADJUSTMENT   "Ripple how many times?" '(5 1 1000 1 1 0 1)
  SF-ADJUSTMENT   "Horizontal Amplitude" '(10 -400 400 1 1 0 1)
  SF-ADJUSTMENT   "Vertical Amplitude" '(10 -400 400 1 1 0 1)
  SF-ADJUSTMENT   "Horizontal Period" '(100 1 400 1 1 0 1)
  SF-ADJUSTMENT   "Vertical Period" '(100 1 400 1 1 0 1)
  SF-OPTION      "Horizontal Waveform" '("Sinewave"
                  "Sawtooth")
  SF-OPTION      "Vertical Waveform" '("Sinewave"
                  "Sawtooth")
  SF-OPTION      "Horizontal Edge Handling" '("Smear"
                  "Wrap"
                  "Blank")
  SF-OPTION      "Vertical Edge Handling" '("Smear"
                  "Wrap"
                  "Blank")
  SF-TOGGLE      "Retain Horizontal Tilability?" TRUE
  SF-TOGGLE      "Retain Vertical Tilability?" TRUE
)




Open up the desired image size. Although the tutorial uses a checkerboard, I happen to like solid noise.

Filters > Render > Clouds > Solid Noise


Run the script

Here's a colorized version (Colors > Colorize)


Experiment with different settings and see what you can come up with!

Cheers!

Art




Here's some samples I've been playing with....

Plastic Wrapped


Tribal Art


Cross-eye stereoimage


Plastic Wrapped Cross-eye stereoimage


_________________
I'd rate you as an upper-middle-lower-mod with pro-novice-inter tendencies.....and a twist of lime! Of course, my rating scale is completely objectively subjective, but ALWAYS consistently inconsistent.


Last edited by fencepost on Mon Jan 27, 2014 10:20 pm, edited 1 time in total.

Share on Facebook Share on Twitter Share on Orkut Share on Digg Share on MySpace Share on Delicious Share on Technorati
Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 1:47 pm  (#2)
Offline
Global Moderator
User avatar

Joined: Apr 07, 2010
Posts: 14182
really nice

_________________


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 2:18 pm  (#3)
Offline
GimpChat Member
User avatar

Joined: Aug 11, 2013
Posts: 123
Location: Ohio
Just picked it up fencepost and works just fine. :bigthup Thanks for the script. :tyspin

_________________


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 2:31 pm  (#4)
Offline
Administrator
User avatar

Joined: Aug 10, 2012
Posts: 12978
Location: Native to NYC living in Arizona, Gimp 2.8 & 2.10, Win 11 PC.
Cool effect, I'd need to give it some thought as to how it might be used.

_________________
"A wise man learns more from a foolish question than a fool can learn from a wise answer"


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 3:32 pm  (#5)
Offline
Script Coder
User avatar

Joined: Apr 13, 2010
Posts: 244
Yeah, this one might be a one-trick pony..... :)

_________________
I'd rate you as an upper-middle-lower-mod with pro-novice-inter tendencies.....and a twist of lime! Of course, my rating scale is completely objectively subjective, but ALWAYS consistently inconsistent.


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 3:35 pm  (#6)
Offline
Administrator
User avatar

Joined: Aug 10, 2012
Posts: 12978
Location: Native to NYC living in Arizona, Gimp 2.8 & 2.10, Win 11 PC.
fencepost wrote:
Yeah, this one might be a one-trick pony..... :)

Sometimes that's all you need, one good trick. ;)

_________________
"A wise man learns more from a foolish question than a fool can learn from a wise answer"


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 5:37 pm  (#7)
Offline
Script Coder
User avatar

Joined: Apr 13, 2010
Posts: 244
Absolutely! :-D

_________________
I'd rate you as an upper-middle-lower-mod with pro-novice-inter tendencies.....and a twist of lime! Of course, my rating scale is completely objectively subjective, but ALWAYS consistently inconsistent.


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 5:42 pm  (#8)
Offline
GimpChat Member
User avatar

Joined: Aug 16, 2012
Posts: 4271
Location: Göteborg, Sweden
fencepost: another nice one! thanks for sharing.

_________________


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 5:42 pm  (#9)
Offline
Script Coder
User avatar

Joined: Apr 13, 2010
Posts: 244
You're welcome! Have fun with it!

_________________
I'd rate you as an upper-middle-lower-mod with pro-novice-inter tendencies.....and a twist of lime! Of course, my rating scale is completely objectively subjective, but ALWAYS consistently inconsistent.


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 6:52 pm  (#10)
Offline
GimpChat Member
User avatar

Joined: Jul 17, 2012
Posts: 2770
interesting effect !



Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 9:01 pm  (#11)
Offline
Administrator
User avatar

Joined: Aug 10, 2012
Posts: 12978
Location: Native to NYC living in Arizona, Gimp 2.8 & 2.10, Win 11 PC.
Esper wrote:
interesting effect !

[ Image ]


Nice look Esper. :bigthup

_________________
"A wise man learns more from a foolish question than a fool can learn from a wise answer"


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 10:25 pm  (#12)
Offline
GimpChat Member
User avatar

Joined: May 16, 2010
Posts: 14709
Location: USA
I had a play with a hex filled pattern layer then a color balance edit. Default script settings by the way. :)


_________________
Edmund Burke nailed it when he said, "The only thing necessary for the triumph of evil is for good men to do nothing."


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 10:42 pm  (#13)
Offline
Administrator
User avatar

Joined: Aug 10, 2012
Posts: 12978
Location: Native to NYC living in Arizona, Gimp 2.8 & 2.10, Win 11 PC.
Rod wrote:
I had a play with a hex filled pattern layer then a color balance edit. Default script settings by the way. :)

[ Image ]


It looks almost like bone. :coolthup

_________________
"A wise man learns more from a foolish question than a fool can learn from a wise answer"


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 10:59 pm  (#14)
Offline
GimpChat Member
User avatar

Joined: Jul 17, 2012
Posts: 2770




Last edited by Esper on Mon Dec 09, 2013 11:24 pm, edited 1 time in total.

Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 11:23 pm  (#15)
Offline
GimpChat Member
User avatar

Joined: May 16, 2010
Posts: 14709
Location: USA
Running patterns through the filter results in some really cool stuff. :)

_________________
Edmund Burke nailed it when he said, "The only thing necessary for the triumph of evil is for good men to do nothing."


Top
 Post subject: Re: Metallic Background
PostPosted: Mon Dec 09, 2013 11:24 pm  (#16)
Offline
GimpChat Member
User avatar

Joined: Jul 17, 2012
Posts: 2770


Top
 Post subject: Re: Metallic Background
PostPosted: Tue Dec 10, 2013 1:21 am  (#17)
Offline
Script Coder
User avatar

Joined: Feb 18, 2011
Posts: 4827
Location: Bendigo Vic. Australia
Great results Esper, the script has so many possible outcomes thanks Fencepost

_________________
No matter how much you push the envelope, it'll still be stationery.


Top
 Post subject: Re: Metallic Background
PostPosted: Tue Dec 10, 2013 4:01 pm  (#18)
Offline
Administrator
User avatar

Joined: Aug 10, 2012
Posts: 12978
Location: Native to NYC living in Arizona, Gimp 2.8 & 2.10, Win 11 PC.
Esper wrote:
[ Image ]

:wow That's nice. :bigthup

_________________
"A wise man learns more from a foolish question than a fool can learn from a wise answer"


Top
 Post subject: Re: Metallic Background
PostPosted: Tue Dec 10, 2013 4:05 pm  (#19)
Offline
GimpChat Member
User avatar

Joined: Mar 19, 2013
Posts: 338
Location: the Netherlands
Looks cool! Loving the cross eye 3D :)


Top
 Post subject: Re: Metallic Background
PostPosted: Tue Dec 10, 2013 5:31 pm  (#20)
Offline
GimpChat Member
User avatar

Joined: Aug 16, 2012
Posts: 4271
Location: Göteborg, Sweden
wow, things are happening in here! nice results, everyone.

_________________


Top
