Layer Adjustments

Rod · **Joined:** May 16, 2010 **Posts:** 14709 **Location:** USA

So i found these cool scripts here
http://the-gimp.deviantart.com/art/Adju ... rs-1473128

But everytime i use any of them i get this same error "set! - unbound variable theLayer"

So i looked at the scripts and this is what one the "pattern adjustment script" - looks like

Code: Select all

;
; pattern-fill-adjustment-layer
;
; Creates a pattern fill "adjustment layer".
;
; Alexander Melcher (a.melchers@planet.nl)
; At xMedia, The Netherlands

; This program is free software; you can redistribute it and/or modify
; it under the terms of the GNU General Public License as published by
; the Free Software Foundation; either version 2 of the License, or
; (at your option) any later version.
;
; This program is distributed in the hope that it will be useful,
; but WITHOUT ANY WARRANTY; without even the implied warranty of
; MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
; GNU General Public License for more details.

; Define the function

(define (script-fu-pattern-fill-adjustment-layer inImage
                                            inLayer
                                            inPattern
                                            inReplaceLayer
   )

   ; Make sure to work on the layer, not the layer mask
   (if (= (car (gimp-drawable-is-layer-mask inLayer)) TRUE)
      (set! theLayer (car (gimp-image-get-active-layer inImage)))
      (set! theLayer inLayer)
   )

   ; Group undo information
   (gimp-undo-push-group-start inImage)

   ; Create the adjustment layer
   (set! adjustment (car (gimp-layer-new inImage
                    (car (gimp-image-width inImage))
                    (car (gimp-image-height inImage))
                    (car (gimp-drawable-type-with-alpha theLayer))
                    "Pattern Fill"
                    100 0)))
   (if (= inReplaceLayer TRUE)
      (begin
         (gimp-layer-set-linked adjustment
                  (car (gimp-layer-get-linked theLayer)))
         (gimp-layer-set-opacity adjustment
                  (car (gimp-layer-get-opacity theLayer)))
      )
      ()
   )

   ; Create the effect
   (set! currentSelection (car (gimp-selection-save inImage)))
   (gimp-image-remove-channel inImage currentSelection)
   (gimp-selection-all inImage)
   (gimp-edit-clear adjustment)
   (set! currentPattern (car (gimp-patterns-get-pattern)))
   (gimp-patterns-set-pattern inPattern)
   (gimp-bucket-fill adjustment 2 0 100 255 FALSE 0 0)
   (gimp-patterns-set-pattern currentPattern)
   (gimp-image-add-layer inImage adjustment -1)
   (if (= inReplaceLayer TRUE)
      (begin
         (gimp-image-remove-layer inImage theLayer)
         (if (= (car (gimp-drawable-is-layer-mask inLayer)) TRUE)
            (gimp-selection-load inLayer)
         (if (= (car (gimp-layer-mask theLayer)) -1)
            (gimp-selection-none inImage)
            (gimp-selection-load (car (gimp-layer-mask theLayer)))
         )
         )
      )
      (gimp-selection-load currentSelection)
   )

   ; Add a layer mask
   (if (= (car (gimp-selection-is-empty inImage)) FALSE)
      (begin
         (set! adjustmentMask (car (gimp-layer-create-mask adjustment 1)))
         (set! currentFgColor (car (gimp-palette-get-foreground)))
         (gimp-palette-set-foreground '(255 255 255))
         (gimp-bucket-fill adjustmentMask 0 0 100 255 FALSE 0 0)
         (gimp-palette-set-foreground currentFgColor)
      )
      (set! adjustmentMask (car (gimp-layer-create-mask adjustment 0)))
   )
   (gimp-image-add-layer-mask inImage adjustment adjustmentMask)

   (if (= inReplaceLayer TRUE)
      (gimp-selection-load currentSelection)
      ()
   )

   ; Group undo information
   (gimp-undo-push-group-end inImage)

   ; Force update
   (gimp-displays-flush)

   ; Return
   (list 1)
)

; Register script-fu-pattern-fill-adjustment-layer

(script-fu-register
    "script-fu-pattern-fill-adjustment-layer"
    "<Image>/Adjustment Layers/Pattern Fill"
    "Creates a pattern fill \"adjustment layer\"."
    "Alexander Melchers"
    "2002, Alexander Melchers, xMedia"
    "7th November 2002"
    "RGB* GRAY*"
    SF-IMAGE      "The Image"             0
    SF-DRAWABLE   "The Layer"             0
    SF-PATTERN    "Pattern"               "Pine?"
    SF-TOGGLE     "Replace Layer"         FALSE
)

All of the scripts give the same error so i imagine it to be a fix that can be applied globally for all of them?

So i was hoping one of you awesome script writers could tell me how to fix them so they work?
I think they would be an awesome addition to Gimp.

Thanks

Oregonian · **Posted:** Thu Jan 13, 2011 1:11 pm **(#2)**

I see others are having the same error message.

PhotoComix · **Joined:** Apr 12, 2010 **Posts:** 5870

are you sure is worth ?
There are several updated "Layer Effect" or "layer adjustment" scripts in the registry, that is 8 years old and apparently doesn't do anything that the others can't do.

(at least judging from the description on the page )

Rod · **Joined:** May 16, 2010 **Posts:** 14709 **Location:** USA

@ PC - seems like these work like a mask though.

@ O Yup, it's almost like something in the scripts are not quite right, but i ran one through the script-fu console and got no errors.
I thought maybe there is something that you have to do before you can run the script.
I tried a few things like
making a selection - didn't work
selecting a layer - didn't work
creating a layer mask - didn't work
selecting the mask in the layer - didn't work either

So i don't know what's up with them.

RobA · **Joined:** Jul 14, 2010 **Posts:** 697

PhotoComix wrote:

are you sure is worth ?
There are several updated "Layer Effect" or "layer adjustment" scripts in the registry, that is 8 years old and apparently doesn't do anything that the others can't do.

(at least judging from the description on the page )

Yes- This is the one I use: http://registry.gimp.org/node/186

-Rob A>

Rod · **Joined:** May 16, 2010 **Posts:** 14709 **Location:** USA

These are a little different though it seems they include
brightness
dodge and burn
lightness

I use layerfx also (python version), but these seem different.
They do not seem to have a lot of control though.Ill throw them in the not-use pile for now. =)

thanks folks.
