 Post subject: online: Inpaint [patch based]
PostPosted: Wed Sep 30, 2015 10:26 am  (#1)
Offline
GimpChat Member
User avatar

Joined: May 09, 2013
Posts: 53
I just tried to remove something from a picture by using the online filter Inpaint [patch based]. I painted the unnecessary object with the same red color(255/100/100) used by the filter and after loading the image - not altering any of the default settings - clicked on "render full image" then download. But the image didn't change at all... So what might I've done wrong? Even if didn't expect the object to be covered perfectly because it is in the middle of two very different image halfs I would expect SOME covering...


Attachments:
File comment: That's the file I uploaded - and it's also the result I get.
blitz-teilt-bild--Maske.jpg [ 114.07 KiB | Viewed 3658 times ]
Share on Facebook Share on Twitter Share on Orkut Share on Digg Share on MySpace Share on Delicious Share on Technorati
Top
 Post subject: Re: online: Inpaint [patch based]
PostPosted: Wed Sep 30, 2015 10:44 am  (#2)
Offline
GimpChat Member
User avatar

Joined: Jan 20, 2013
Posts: 14831
Location: roma, italy
only two comments:
1-red should be 255 0 0
2-to paint you should use pencil (brush with hard edge) not pen

_________________
"Where am I ?"


Top
 Post subject: Re: online: Inpaint [patch based]
PostPosted: Wed Sep 30, 2015 11:47 am  (#3)
Offline
GimpChat Member
User avatar

Joined: May 09, 2013
Posts: 53
My fault, it is 255/0/0 in both cases, I've looked at the wrong values in both cases. You are right with the pencil but even though the outer borders are wrong color, the inner part should be correct and should produce at least a slight result. I've redone the picture with a hard pencil - but the result is the same, nothing changes.

[Several investigative minutes later]
I have found the reason! I had used the online editor from Pixlr to create the red mask on the picture. I carefully chose the color 255/0/0, used the pencil and saved the image as jpg to disk, then used it with GMic online. Meanwhile I've started Gimp and tested it. In Gimp the Inpaint color dialog offers a color picker. So I opened the picture I edited with Pixlr and used the color picker on the red. And guess what - it sais 254/0/0 and 255/1/0! So I guess the color got corrupted by saving as JPG.

I get a perfect result when I use Gimp to create the red mask and the use the G'Mic plugin. I even don't get a perfect result when I use the Pixlr editor with a pencil and when I save as PNG - so I guess the problem was a) using JPG to save before letting G'Mic do its work and b) the Pixlr pencil is not that color exact on the edges...

BTW: Weird in the online version is that I only get Inpaint [patch based] when I click on Inpaint [holes], all filters seem to be displaced by one.

Weird too, the online version of Inpaint [patch based] seems to work different? I have used the same values in the two pictures. The one with the red marks was created completly online. Though the red mask was not that perfect I wonder why the filling is different... especially in the sky.


Attachments:
File comment: G'Mic result when red mask is created in Pixlr with pencil, saved as PNG...
blitz-teilt-bild--maske-pixlr-pen2_gmic-result.jpg [ 74.18 KiB | Viewed 3615 times ]
File comment: Does work with pencil and when only using Gimp ;).
blitz-teilt-bild--.maske3--gimp-works.jpg [ 130.11 KiB | Viewed 3616 times ]


Last edited by spacepenguin on Wed Sep 30, 2015 11:57 am, edited 1 time in total.
Top
 Post subject: Re: online: Inpaint [patch based]
PostPosted: Wed Sep 30, 2015 11:55 am  (#4)
Offline
GimpChat Member
User avatar

Joined: Sep 24, 2010
Posts: 12832
Only can use a hard brush (no grayscale in the brush; see what I mean below). :)


Attachments:
hs.png [ 32.78 KiB | Viewed 3614 times ]

_________________
Lyle

Psalm 109:8

Top
 Post subject: Re: online: Inpaint [patch based]
PostPosted: Wed Sep 30, 2015 2:52 pm  (#5)
Offline
GimpChat Member
User avatar

Joined: May 09, 2013
Posts: 53
@lylejk: Yes, I know. But the hard brush (pencil) in Pixlr obviously is not 100% hard and JPG is a lossy format so that it might come to slight color differences when saving.

Just tested it again online, now [patch based] is [patch based] again, fine, whatever caused the displacement. And it also renders the image correctly now, no green in the sky anymore...
