ok. the first plugin I tested "SSG" crashes GIMP 2.99.19 on closing tab, opening existing .xcf with it or closing gimp. Based on its code I see no offenses /* This file is an image processing operation for GEGL
*
* GEGL is free software; you can redistribute it and/or
* modify it under the terms of the GNU Lesser General Public
* License as published by the Free Software Foundation; either
* version 3 of the License, or (at your option) any later version.
*
* GEGL is distributed in the hope that it will be useful,
* but WITHOUT ANY WARRANTY; without even the implied warranty of
* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
* Lesser General Public License for more details.
*
* You should have received a copy of the GNU Lesser General Public
* License along with GEGL; if not, see <https://www.gnu.org/licenses/>.
*
*
* 2023 Beaver (GEGL SSG (stroke, shadow, glow) )
*/
#include "config.h"
#include <glib/gi18n-lib.h>
#ifdef GEGL_PROPERTIES
/*
June 25 2023 - Recreation of SSG's GEGL Graph. If you feed this info to Gimp's
GEGL Graph it will allow to to text the plugin without installing it.
id=1
opacity value=1.5
median-blur alpha-percentile=0 radius=1
gaussian-blur std-dev-x=1 std-dev-y=1
dropshadow x=0 y=0 radius=0 grow-radius=9 opacity=2
xor aux=[ ref=1 ]
color-overlay value=#ffffff
id=2 src-atop aux=[ ref=2 layer gaussian-blur std-dev-x=0 std-dev-y=0 ]
*/
/* Should correspond to GeglMedianBlurNeighborhood in median-blur.c */
enum_start (gegl_stroke_grow_shape2)
enum_value (GEGL_stroke_GROW_SHAPE_SQUARE2, "square", N_("Square"))
enum_value (GEGL_stroke_GROW_SHAPE_CIRCLE2, "circle", N_("Circle"))
enum_value (GEGL_stroke_GROW_SHAPE_DIAMOND2, "diamond", N_("Diamond"))
enum_end (GeglstrokeGrowShape2)
property_enum (grow_shape, _("Grow shape"),
GeglstrokeGrowShape2, gegl_stroke_grow_shape2,
GEGL_stroke_GROW_SHAPE_CIRCLE2)
description (_("The shape to expand or contract the stroke in"))
property_color (colorssg, _("Color Overlay"), "#ffffff")
property_double (x, _("Horizontal position of SSG"), 0.0)
description (_("Horizontal shadow offset"))
ui_range (-40, 40)
ui_steps (1, 5)
ui_meta ("unit", "pixel-distance")
ui_meta ("axis", "x")
property_double (y, _("Vertical position of SSG"), 0.0)
description (_("Vertical shadow offset"))
ui_range (-40, 40)
ui_steps (1, 5)
ui_meta ("unit", "pixel-distance")
ui_meta ("axis", "y")
property_double (blurstroke, _("Blur to create Shadow or Glow"), 0.5)
value_range (0.0, G_MAXDOUBLE)
ui_range (0.0, 100.0)
ui_steps (1, 5)
ui_gamma (1.5)
ui_meta ("unit", "pixel-distance")
property_int (stroke, _("Grow radius of SSG"), 9)
value_range (0, 300)
ui_range (0, 50)
ui_steps (1, 5)
ui_gamma (1.5)
ui_meta ("unit", "pixel-distance")
description (_("The distance to expand the stroke/shadow before blurring; a negative value will contract the shadow instead"))
property_int (radius, _("Make the SSG go inward or outward"), 1)
value_range (-250, 10)
ui_range (0, 2)
description (_("Hidden Settings are meant for Graphs and removing edge pixels with the erase or split blend mode"))
/*
property_file_path(image, _("Image file overlay"), "")
description (_("Source image file path (png, jpg, raw, svg, bmp, tif, ...)"))
ui_meta ("role", "output-extent")
property_double (blur2, _("Blur Image file Overlay"), 0.0)
description (_("A light blur to smooth the image file overlay"))
value_range (0, 40.0)
ui_range (0, 40.0)
ui_gamma (1.5)
ui_meta ("role", "output-extent")
property_double (hue, _("Hue Rotation for Image file overlay"), 0.0)
description (_("Color rotation that adjust the image file'"))
value_range (-180.0, 180.0)
ui_meta ("role", "output-extent")
*/
property_double (opacityssg, _("Opacity"), 2)
value_range (0.0, 4.0)
ui_steps (0.0, 4.0)
#else
#define GEGL_OP_META
#define GEGL_OP_NAME ssg
#define GEGL_OP_C_SOURCE ssg.c
#include "gegl-op.h"
static void attach (GeglOperation *operation)
{
GeglNode *gegl = operation->node;
GeglColor *ssg_hidden_color = gegl_color_new ("#000000");
GeglNode*input = gegl_node_get_input_proxy (gegl, "input");
GeglNode*output = gegl_node_get_output_proxy (gegl, "output");
GeglNode*image = gegl_node_new_child (gegl,
"operation", "gegl:nop",
NULL);
GeglNode*color = gegl_node_new_child (gegl,
"operation", "gegl:color-overlay",
NULL);
GeglNode*atop = gegl_node_new_child (gegl,
"operation", "gegl:src-atop",
NULL);
GeglNode*opacity = gegl_node_new_child (gegl,
"operation", "gegl:opacity", "value", 2.0,
NULL);
GeglNode*median = gegl_node_new_child (gegl,
"operation", "gegl:median-blur", "alpha-percentile", 0.0, "abyss-policy", GEGL_ABYSS_NONE,
NULL);
GeglNode*ssg = gegl_node_new_child (gegl,
"operation", "gegl:dropshadow",
"color", ssg_hidden_color, NULL);
GeglNode*blur = gegl_node_new_child (gegl,
"operation", "gegl:gaussian-blur", "std-dev-x", 0.5, "std-dev-y", 0.5, "clip-extent", FALSE, "abyss-policy", 0,
NULL);
GeglNode*blur2 = gegl_node_new_child (gegl,
"operation", "gegl:gaussian-blur", "clip-extent", FALSE, "abyss-policy", 0,
NULL);
GeglNode*id1 = gegl_node_new_child (gegl,
"operation", "gegl:nop",
NULL);
GeglNode*hue = gegl_node_new_child (gegl,
"operation", "gegl:hue-chroma",
NULL);
GeglNode*hopacity = gegl_node_new_child (gegl,
"operation", "gegl:opacity", "value", 1.5,
NULL);
GeglNode*xor = gegl_node_new_child (gegl,
"operation", "gimp:layer-mode", "layer-mode", 60, NULL);
gegl_operation_meta_redirect (operation, "colorssg", color, "value");
gegl_operation_meta_redirect (operation, "opacityssg", opacity, "value");
gegl_operation_meta_redirect (operation, "stroke", ssg, "grow-radius");
gegl_operation_meta_redirect (operation, "blurstroke", ssg, "radius");
gegl_operation_meta_redirect (operation, "x", ssg, "x");
gegl_operation_meta_redirect (operation, "y", ssg, "y");
gegl_operation_meta_redirect (operation, "grow_shape", ssg, "grow-shape");
/* gegl_operation_meta_redirect (operation, "image", image, "src");
gegl_operation_meta_redirect (operation, "hue", hue, "hue");
gegl_operation_meta_redirect (operation, "blur2", blur2, "std-dev-x");
gegl_operation_meta_redirect (operation, "blur2", blur2, "std-dev-y"); */
gegl_operation_meta_redirect (operation, "radius", median, "radius");
gegl_node_link_many (input, hopacity, median, blur, id1, ssg, xor, color, atop, opacity, output, NULL);
gegl_node_link_many (image, hue, blur2, NULL);
gegl_node_connect (xor, "aux", id1, "output");
gegl_node_connect (atop, "aux", blur2, "output");
}
static void
gegl_op_class_init (GeglOpClass *klass)
{
GeglOperationClass *operation_class;
operation_class = GEGL_OPERATION_CLASS (klass);
operation_class->attach = attach;
gegl_operation_class_set_keys (operation_class,
"name", "sg:ssg",
"title", _("Add a Stroke, Shadow or Glow"),
"reference-hash", "3ado316vg22a00x03vv5sb2ac",
"description", _("Make a duplicate layer of image you want to apply SSG to, then apply SSG to the top or bottom duplicate layer. SSG is an enhanced fork of the drop shadow filter that starts as a outline, knocks out the original image and allows image file overlays. "
""),
"gimp:menu-path", "<Image>/Filters/Text Styling",
"gimp:menu-label", _("Stroke Shadow Glow (SSG)..."),
NULL);
}
#endif
If SSG Is causing a problem, its likely its problem is the same as all other plugins. Meaning if I solve SSG's hidden problem all the other plugins will have their problem solved as well.
|
|
